EM619001 200A 600VDC Din Rail RS485 Modbus Net Metering DC Smart PV Solar Bidirectional Meter

EM619001 is used to monitor and control DC system. They also support limit alarm, analog output, digital input, relay output and communication functions. It has the function of energy metering, data processing, real time monitoring and LCD display.

The meter can have relay alarm output and digital input function; You can set the ratio, alarm, and communication through the meter panel keys according to different requirements. The meter can have event recording of switch (Modbus protocol), programming and event setting records(645 protocol), instantaneous and timing freeze function of data (645 protocol), maximum and minimum value recording function of voltage and current power. It is suitable for DC energy metering of EV charging piles, battery system, base station, solar panels etc.

Inquire Now Next Product

Product Details

EM619001 Product Features

Din Rail Mount, Shunt Sampling, Class 1

Measuring Current up to 2000A

Voltage Input DC5~1000V, Current Input 75mV(max)

Bi-directional Measurement

RS485 Communication with DLT645/Modbus Protocol

Over-current/ Over-load Alarm

LCD Backlight, Multi-tariffs(RTC), Monthly Records

Built-in Auxiliary Relay for Over-current Disconnect

Product Parameters

EM619001	Din Rail DC Measuring Device
Reference voltage	DC 5V-1000V
Current	Measuring Current up to 2000A
Self-powered power supply	85~265V AC/ 85~265V DC
Current / Voltage accuracy	0.5%
Operation temp.	-25℃~+70℃
Active power accuracy	1.0%
Active accuracy class	Cl.1.0
Humidity	95%
Communication	RS485 Communication
Communication protocol	DLT645/Modbus
Impulse constant	1000 imp/kWh
LCD display	LCD 6+2
Power consumption	≤0.4W,≤8VA
AC withstand voltage	4400V/min

Product Dimension and Diagram

EM619001 200A 600VDC Din Rail RS485 Modbus Net Metering DC Smart PV Solar Bidirectional Meter

Product Application

EM619001 rail-mounted DC power meter with 1000V DC input channels, designed for LVDC application-telecommunications base stations, DC charging piles, solar photovoltaic and other applications, this series of meters can measure the voltage, current, power and forward and reverse energy and so on in the DC system.The actual use of the site, you can measure the total power, but also measure the energy within a specified period of time. The test results can be used for local display, but also with industrial control equipment, computers to form a measurement and control system.
