EM613002 Din Rail Mount 100A Solar Smart Shunt RS485 Wifi DC Energy Meter for Telecom Tower
· 40~400V DC Metering Shunt Sampling
· RS485 DLT645/Modbus
· Automatic Scrolling LCD Display
· Alarming when Over/Under-Voltage/Current Settable Threshold
· Event Log
· 4 Tariffs with 8 Time Slots
EM613002 DC Energy Meter: Key Features
1. DC Electrical Measurement
The EM613002 uses shunt sampling to measure electrical parameters in DC power systems. It records DC voltage, current, instantaneous power and accumulated import and export energy, supporting monitoring of PV generation, battery storage and DC loads.
2. DIN-Rail Installation
The DIN-rail design enables installation in compatible electrical distribution and monitoring cabinets. It is suitable for system integrators who need to incorporate DC energy measurement into an existing power monitoring system.
3. RS485 Communication
The meter supports RS485 communication, with DLT645 specified in the product parameter table. It enables data access and integration with compatible monitoring equipment and software. Confirm protocol compatibility and any wireless communication options when selecting the product configuration.
4. Electrical Alarms and Event Records
The EM613002 supports configurable voltage and current alarm thresholds and event logging. These functions help operators identify abnormal electrical conditions and review recorded events during system monitoring and maintenance.
5. Multi-Tariff Function
The meter supports four tariffs and eight time slots for applications requiring multi-tariff energy management. Confirm tariff configuration and the required functions with IVY Metering before ordering.
EM613002 Product Specifications
| Parameter | Specification |
|---|---|
| Model | EM613002 |
| Product type | DIN-rail DC energy meter |
| Measurement method | Shunt sampling |
| Reference voltage | 40–400 VDC |
| Reference current | 10–240 A |
| Energy measurement | Import and export energy |
| Accuracy class | Class 1 |
| Communication interface | RS485 |
| Communication protocol | DLT645, as listed in the parameter table |
| Pulse constant | 100 imp/kWh |
| Display | LCD 6+2 |
| Operating temperature | -20°C to +70°C |
| Average humidity | 75% |
| Relative humidity | 95% |
| Power consumption | ≤0.4 W, ≤8 VA |
| Alarm functions | Configurable voltage and current thresholds |
| Event logging | Supported |
| Tariff function | 4 tariffs, 8 time slots |
| Listed standard | GB/T 17708-2017, Static DC Energy Meter |
Typical Applications
Solar PV Energy Monitoring
Monitor DC electrical parameters on the photovoltaic generation side to support energy measurement and performance monitoring before power conversion.
Battery Energy Storage Systems
Measure DC voltage, current, power and accumulated energy in compatible DC battery storage and power distribution systems.
Telecom Base Stations
Monitor DC power flows in telecommunications power systems to support energy data collection and operational monitoring.
DC Power Monitoring Systems
Integrate the meter into compatible DC monitoring systems where shunt-based measurement and RS485 communication meet the project requirements.
Frequently Asked Questions
What does the EM613002 DC energy meter measure?
The EM613002 measures DC voltage, current and instantaneous power, and records accumulated import and export energy in compatible DC systems.
What is the measurement range of the EM613002?
The published product parameters specify a reference voltage of 40–400 VDC and a reference current range of 10–240 A using shunt sampling.
Does the EM613002 support RS485 communication?
Yes. RS485 communication is listed in the product parameters, with DLT645 specified as the communication protocol. Confirm any additional protocol requirements against the selected model configuration.
Where can the EM613002 be used?
Typical applications include solar PV monitoring, battery energy storage, telecom base stations and compatible DC power monitoring systems.
How can I confirm the right configuration for my project?
Contact IVY Metering with your DC voltage range, maximum current, shunt requirements, communication protocol and application details. The technical team can help confirm whether the EM613002 configuration matches your system.
Product Dimension
Product Application
EM series DC energy meters on the photovoltaic power generation DC side and the battery energy storage DC side respectively.
DC Energy Meter which could record electrical parameters such as DC Voltage, Export Current, Import Current, instantaneous Power with direction, accumulate Import and Export Energy values.
These parameters are mostly needed in DC energy generation or DC load such as Solar PV System.
